SIMATIC S7-300, Analog input SM 331, single channel Isolated 250 V AC, 6 AI thermocouples Type B, E, J, K, L, N, R, S, T Voltage: +/-25MV to +/-1V 16 bit, 50ms, 1x 40-pole

6ES7331-7PE10-0AB0 là mô đun mở rộng đầu vào tương tự cho PLC S7-300 do hãng SIEMENS phát triển & sản xuất với thương hiệu SIMATIC thuộc họ S7-300. SM 331 6AI 16bit Thermocouple SIEMENS 6ES7331-7PE10-0AB0 được SIEMENSIM.COM phát triển và phân phối rộng rãi trên thị trường Việt Nam. Nếu quý khách hàng đang có nhu cầu cần tư vấn hay mua 6ES7331-7PE10-0AB0 thì hãy liên hệ SIEMENS INDUSTRY MALL để được hỗ trợ một cách tận tâm, nhanh chóng và hiệu quả nhé.

Mục lục

Tóm tắt thông số kỹ thuật 6ES7331-7PE10-0AB0

Mã sản phẩm	6ES7331-7PE10-0AB0
Dòng sản phẩm	SIMATIC S7-300, SM 331
Hãng sản xuất	SIEMENS
Số lượng đầu vào tương tự	6AI, 16bit, Thermocouple
Nguồn cung cấp	24 V DC
Kích thước (RxCxS)	40x125x120 mm
Trọng lượng	272 g

Chi tiết thông số kỹ thuật 6ES7331-7PE10-0AB0

Tải về datasheet (pdf): Tại đây!

Supply voltage
Load voltage L+
● Rated value (DC)	24 V
● Reverse polarity protection	Yes
Input current
from load voltage L+ (without load), max.	150 mA
from backplane bus 5 V DC, max.	100 mA
Power loss
Power loss, typ.	2.2 W
Analog inputs
Number of analog inputs	6
permissible input voltage for voltage input (destruction limit), max.	35 V; 35 V continuous, 75 V for max. 1 s (mark to space ratio 1:20)
Constant measurement current for resistance-type transmitter, typ.	0.7 mA
Input ranges
● Voltage	Yes
● Current	No
● Thermocouple	Yes
● Resistance thermometer	No
● Resistance	No
Input ranges (rated values), voltages
● 0 to +10 V	No
● 1 V to 5 V	No
● 1 V to 10 V	No
● -1 V to +1 V	Yes
— Input resistance (-1 V to +1 V)	10 MΩ
● -10 V to +10 V	No
● -2.5 V to +2.5 V	No
● -250 mV to +250 mV	Yes
— Input resistance (-250 mV to +250 mV)	10 MΩ
● -5 V to +5 V	No
● -50 mV to +50 mV	Yes
— Input resistance (-50 mV to +50 mV)	10 MΩ
● -500 mV to +500 mV	Yes
— Input resistance (-500 mV to +500 mV)	10 MΩ
● -80 mV to +80 mV	Yes
— Input resistance (-80 mV to +80 mV)	10 MΩ
Input ranges (rated values), currents
● 0 to 20 mA	No
● -10 mA to +10 mA	No
● -20 mA to +20 mA	No
● -3.2 mA to +3.2 mA	No
● 4 mA to 20 mA	No
Input ranges (rated values), thermocouples
● Type B	Yes
— Input resistance (Type B)	10 MΩ
● Type C	Yes
— Input resistance (Type C)	10 MΩ
● Type E	Yes
— Input resistance (Type E)	10 MΩ
● Type J	Yes
— Input resistance (type J)	10 MΩ
● Type K	Yes
— Input resistance (Type K)	10 MΩ
● Type L	Yes
— Input resistance (Type L)	10 MΩ
● Type N	Yes
— Input resistance (Type N)	10 MΩ
● Type R	Yes
— Input resistance (Type R)	10 MΩ
● Type S	Yes
— Input resistance (Type S)	10 MΩ
● Type T	Yes
— Input resistance (Type T)	10 MΩ
● Type U	Yes
— Input resistance (Type U)	10 MΩ
● Type TXK/TXK(L) to GOST	Yes
— Input resistance (Type TXK/TXK(L) to GOST)	10 MΩ
Input ranges (rated values), resistance thermometer
● Cu 10	No
● Ni 100	No
● Ni 1000	No
● LG-Ni 1000	No
● Ni 120	No
● Ni 200	No
● Ni 500	No
● Pt 100	No
● Pt 1000	No
● Pt 200	No
● Pt 500	No
Input ranges (rated values), resistors
● 0 to 150 ohms	No
● 0 to 300 ohms	No
● 0 to 600 ohms	No
● 0 to 6000 ohms	No
Thermocouple (TC)
Temperature compensation
— parameterizable	Yes
— internal temperature compensation	Yes
— external temperature compensation with Pt100	Yes
— external temperature compensation with compensations socket	Yes
— for definable comparison point temperature	Yes
Characteristic linearization
● parameterizable	Yes
— for thermocouples	Type B, E, J, K, L, N, R, S. T, U, C, TXK, XK(L)
— for resistance thermometer	No
Cable length
● shielded, max.	200 m
Analog value generation for the inputs
Integration and conversion time/resolution per channel
● Resolution with overrange (bit including sign), max.	16 bit; Two’s complement
● Integration time, parameterizable	Yes
● Basic conversion time (ms)	30 / 50 / 60 / 300 ms
● Integration time (ms)	10/ 16.67/ 20/ 100 ms
Encoder
Connection of signal encoders
● for voltage measurement	Yes
Errors/accuracies
Operational error limit in overall temperature range
● Voltage, relative to input range, (+/-)	Operating error at 0 … 60 °C: ±0.12% @ ±25 mV, ±0.08% @ ±50 mV, ±0.6% @ ±80 mV, ±0.05% @ ±250 mV, ±0.05% @ 500 mV, ±0.05% @ ±1 V
● Thermocouple, relative to input range, (+/-)	See manual for details
Basic error limit (operational limit at 25 °C)
● Voltage, relative to input range, (+/-)	See manual for details
● Thermocouple, relative to input range, (+/-)	See manual for details
Interrupts/diagnostics/status information
Diagnostics function	Yes; Parameterizable
Alarms
● Diagnostic alarm	Yes; channel by channel
● Limit value alarm	Yes; Parameterizable
● Hardware interrupt	Yes; Parameterizable
Diagnoses
● Diagnostic information readable	Yes
Diagnostics indication LED
● Group error SF (red)	Yes
Potential separation
Potential separation analog inputs
● between the channels	Yes
● between the channels, in groups of	1
● between the channels and backplane bus	Yes
● between the channels and the power supply of the electronics	Yes
Isolation
Isolation tested with	2 500 V DC
Connection method
required front connector	40-pin
Dimensions
Width	40 mm
Height	125 mm
Depth	120 mm
Weights
Weight, approx.	272 g
