SIMATIC S7-300 Regulated power supply PS307 input: 120/230 V AC, output: 24 V DC/2 A
6ES7307-1BA01-0AA0 là mô đun cấp nguồn cho PLC S7-300 (CPU) do hãng SIEMENS phát triển & sản xuất với thương hiệu SIMATIC thuộc họ S7-300. PS 307 120/230VAC 24VDC/2A 6ES7307-1BA01-0AA0 được SIEMENSIM.COM phát triển và phân phối rộng rãi trên thị trường Việt Nam. Nếu quý khách hàng đang có nhu cầu cần tư vấn hay mua 6ES7307-1BA01-0AA0 thì hãy liên hệ SIEMENS INDUSTRY MALL để được hỗ trợ một cách tận tâm, nhanh chóng và hiệu quả nhé.
Mục lục
Tóm tắt thông số kỹ thuật 6ES7307-1BA01-0AA0
| Mã sản phẩm | 6ES7307-1BA01-0AA0 |
| Dòng sản phẩm | SIMATIC S7-300, PS 307 |
| Hãng sản xuất | SIEMENS |
| Nguồn cung cấp | 120/230 V AC |
| Nguồn đầu ra | 24 V DC/ 2 A |
| Kích thước (RxCxS) | 40x125x120 mm |
| Trọng lượng | 400 g |
Chi tiết thông số kỹ thuật 6ES7307-1BA01-0AA0
Tải về datasheet (pdf): Tại đây!
| Input | |
| Input | 1-phase AC |
| ● Note | Automatic range selection |
| supply voltage | |
| ● 1 at AC rated value | 120 V |
| ● 2 at AC rated value | 230 V |
| input voltage | |
| ● 1 at AC | 85 … 132 V |
| ● 2 at AC | 170 … 264 V |
| Wide-range input | No |
| Overvoltage resistance | 2.3 × Vin rated, 1.3 ms |
| Mains buffering | at Vin = 93/187 V |
| Mains buffering at Iout rated, min. | 20 ms; at Vin = 93/187 V |
| Rated line frequency 1 | 50 Hz |
| Rated line frequency 2 | 60 Hz |
| Rated line range | 47 … 63 Hz |
| input current | |
| ● at rated input voltage 120 V | 0.9 A |
| ● at rated input voltage 230 V | 0.5 A |
| Switch-on current limiting (+25 °C), max. | 22 A |
| duration of inrush current limiting at 25 °C | |
| ● maximum | 3 ms |
| I²t, max. | 1 A²·s |
| Built-in incoming fuse | T 1.6 A/250 V (not accessible) |
| Protection in the mains power input (IEC 898) | Recommended miniature circuit breaker: 3 A characteristic C |
| Output | |
| Output | Controlled, isolated DC voltage |
| Rated voltage Vout DC | 24 V |
| ● output voltage at output 1 at DC rated value | 24 V |
| Total tolerance, static ± | 3 % |
| Static mains compensation, approx. | 0.1 % |
| Static load balancing, approx. | 0.2 % |
| Residual ripple peak-peak, max. | 50 mV |
| Residual ripple peak-peak, typ. | 5 mV |
| Spikes peak-peak, max. (bandwidth: 20 MHz) | 150 mV |
| Spikes peak-peak, typ. (bandwidth: 20 MHz) | 20 mV |
| product function output voltage adjustable | No |
| Output voltage setting | – |
| Status display | Green LED for 24 V OK |
| On/off behavior | No overshoot of Vout (soft start) |
| Startup delay, max. | 2 s |
| Voltage rise, typ. | 10 ms |
| Rated current value Iout rated | 2 A |
| Current range | 0 … 2 A |
| supplied active power typical | 48 W |
| short-term overload current | |
| ● on short-circuiting during the start-up typical | 9 A |
| ● at short-circuit during operation typical | 9 A |
| duration of overloading capability for excess current | |
| ● on short-circuiting during the start-up | 90 ms |
| ● at short-circuit during operation | 90 ms |
| Parallel switching for enhanced performance | Yes |
| Numbers of parallel switchable units for enhanced performance | 2 |
| Efficiency | |
| Efficiency at Vout rated, Iout rated, approx. | 84 % |
| Power loss at Vout rated, Iout rated, approx. | 9 W |
| Closed-loop control | |
| Dynamic mains compensation (Vin rated ±15 %), max. | 0.1 % |
| Dynamic load smoothing (Iout: 50/100/50 %), Uout ± typ. | 0.8 % |
| Load step setting time 50 to 100%, typ. | 0.5 ms |
| Load step setting time 100 to 50%, typ. | 0.5 ms |
| setting time maximum | 1 ms |
| Protection and monitoring | |
| Output overvoltage protection | Additional control loop, shutdown at < 28.8 V, automatic restart |
| Current limitation | 2.2 … 2.6 A |
| property of the output short-circuit proof | Yes |
| Short-circuit protection | Electronic shutdown, automatic restart |
| enduring short circuit current RMS value | |
| ● maximum | 2 A |
| Overload/short-circuit indicator | – |
| Safety | |
| Primary/secondary isolation | Yes |
| galvanic isolation | Safety extra-low output voltage Uout acc. to EN 60950-1 and EN 50178 |
| Protection class | Class I |
| leakage current | |
| ● maximum | 3.5 mA |
| ● typical | 0.5 mA |
| Degree of protection (EN 60529) | IP20 |
| Approvals | |
| CE mark | Yes |
| UL/cUL (CSA) approval | cULus-Listed (UL 508, CSA C22.2 No. 142), File E143289 |
| Explosion protection | IECEx Ex nA nC IIC T4 Gc; ATEX (EX) II 3G Ex nA nC IIC T4 Gc; cULus (ANSI/ISA 12.12.01, CSA C22.2 No.213) Class I, Div. 2, Group ABCD, T4, File E330455 |
| certificate of suitability NEC Class 2 | No |
| FM approval | Class I, Div. 2, Group ABCD, T4 |
| CB approval | No |
| certificate of suitability EAC approval | Yes |
| Marine approval | In S7-300 system |
| EMC | |
| Emitted interference | EN 55022 Class B |
| Supply harmonics limitation | not applicable |
| Noise immunity | EN 61000-6-2 |
| environmental conditions | |
| ambient temperature | |
| ● during operation | 0 … 60 °C |
| — Note | with natural convection |
| ● during transport | -40 … +85 °C |
| ● during storage | -40 … +85 °C |
| Humidity class according to EN 60721 | Climate class 3K3, 5 … 95% no condensation |
| Mechanics | |
| Connection technology | screw-type terminals |
| Connections | |
| ● Supply input | L, N, PE: 1 screw terminal each for 0.5 … 2.5 mm² single-core/finely stranded |
| ● Output | L+, M: 2 screw terminals each for 0.5 … 2.5 mm² |
| ● Auxiliary | – |
| width of the enclosure | 40 mm |
| height of the enclosure | 125 mm |
| depth of the enclosure | 120 mm |
| required spacing | |
| ● top | 40 mm |
| ● bottom | 40 mm |
| ● left | 0 mm |
| ● right | 0 mm |
| Weight, approx. | 0.4 kg |
| product feature of the enclosure housing can be lined up | Yes |
| Installation | Can be mounted onto S7 rail |
| mechanical accessories | Mounting adapter for standard mounting rail (6EP1971-1BA00) |
| MTBF at 40 °C | 2 320 078 h |
| other information | Specifications at rated input voltage and ambient temperature +25 °C (unless otherwise specified) |
